Alligator Clip TP-AC5
€ 1.50
The Alligator Clip TP-AC5 is a small sized nickel plated steel alligator clip with color coding sleeve. The clip can be used on any measuring lead with 4 mm banana plugs. They can also be connected to a wire using a screw. The special construction allows to clamp both thin and thicker wires, up to 10 mm.
The Alligator Clip TP-AC5 - Set of 8: Green, Blue, Yellow, Red, 4 Black comes in a set containing 8 alligator clips: a green one, a blue one, a yellow one, a red one and four black ones. Alligator clips can also be ordered individually.
- Alligator Clip TP-AC5 - Set of 8: Green, Blue, Yellow, Red, 4 Black
- Alligator Clip TP-AC5 - Green
- Alligator Clip TP-AC5 - Blue
- Alligator Clip TP-AC5 - Yellow
- Alligator Clip TP-AC5 - Red
- Alligator Clip TP-AC5 - Black
Order code: TP-AC5-Set
EAN: 7423654093021
Price: 9.80
Category: Alligator clips & test probes
The table below shows detailed specifications of the Alligator Clip TP-AC5.
Each clip | |
|---|---|
| Connector | 4 mm banana socket |
| Rated voltage | 60 V |
| Rated current | 5 A |
| Dimensions | |
| Length | 60 mm |
| Width | 9 mm |
| Height | 14 mm |
| Clamping range | 10 mm |
| Weight | 3 g |
| Color | green, blue, yellow, red or black |
The Alligator Clip TP-AC5 is available in 5 different colors or in one set of 8:
| Order code | EAN | Price |
|---|---|---|
| TP-AC5-Set | 7423654093021 | € 9.80 |
| TP-AC5-Green | 7423623424412 | € 1.50 |
| TP-AC5-Blue | 7423621212202 | € 1.50 |
| TP-AC5-Yellow | 7423628755771 | € 1.50 |
| TP-AC5-Red | 7423626349309 | € 1.50 |
| TP-AC5-Black | 7423637918969 | € 1.50 |
The Alligator Clip TP-AC5 is delivered with:
| Amount | Item |
|---|---|
| 1 | Alligator Clip TP-AC5 - Green |
| 1 | Alligator Clip TP-AC5 - Blue |
| 1 | Alligator Clip TP-AC5 - Yellow |
| 1 | Alligator Clip TP-AC5 - Red |
| 4 | Alligator Clip TP-AC5 - Black |
